| 1 |
AS/NZS3112-Fig2.5 |
pressure test apparatus for insulation on insulated plug pins at high temperature |
| 2 |
AS/NZS3112-Fig2.6 |
impact test apparatus for insulation on insulated plug pins at low temperature |
| 3 |
AS/NZS3112-Fig2.9 |
Temperature rise testing box |
| 4 |
AS/NZS3112-Fig2.10 |
Copper of temperature rise testing |
| 5 |
AS/NZS3112-Fig2.8 |
Plug bending test device |
| 6 |
AS/NZS3112-Fig3.1 a.b.c |
gauge for depth of no-contact test |
| 7 |
AS/NZS3112-Fig3.6 |
device for checking the resistance to lateral strain (three pin gauge) |
| 8 |
AS/NZS3112-Fig3.7 |
device for checking the resistance to lateral strain (two pin gauge) |
| 9 |
AS/NZS3112 figure A1 |
gauge for three-pin 250 v max flat-pin plugs |
| 10 |
AS/NZS3112 figure B1 |
gauge for two-pin flat-pin 125 v max. plugs (with parallel pins) |
| 11 |
AS/NZS3112 figure C1 |
Three-pin test plug with flat pins for full insertion test and the finger test during normal insertion test. |
| 12 |
AS/NZS3112 figure D1 |
Three-pin test plug with flat pins for abnormal insertion test. |
| 13 |
AS/NZS3112 figure F1 |
Plugs and socket-outlets for use in extra-low voltage circuits |
| 14 |
AS/NZS3112 figure G1 |
Three-pin test plug with flat and round pins for the full-insertion test and test finger test during normal insertion test |
| 15 |
AS/NZS3112-2.13.9.1 |
18N Australia plug testing device |
| 16 |
Item 3.3.4.1 |
Test gauge of Minimum Pullout force |
| 17 |
Item 2.3.2 /figure 2.3 |
Not go gauge of socket aperture |
| 18 |
Item 3.14.8.2/figure 2.1(a),(b),(c) |
Plug of socket temperature rise testing |
| 19 |
Item 2.8.1 |
Test pin of distance testing gauge |
