The product has a precise temperature humidity and light control system, which provides various environmental simulation conditions for industrial research and biotechnology testing. It’s widely used in drug and food processing, etc.
Applications:
- Drug
- Food processing
Specification:
|
Model
|
JY-LDS- 175GY-N
|
|
Temperature & Humidity & Light
|
|
|
Temperature Range(℃)
|
Without Illumination:0~65
With Illumination:10~60 |
|
Temperature Fluctuation
|
High±0.5℃、Low±2℃
|
|
Temperature Uniformity (℃)
|
±2
|
|
Humidity Range(RH)
|
30~95%
|
|
Humidity Stability(RH)
|
±3%RH
|
|
Temperature Resolution(℃)
|
0.1
|
|
Illumination(LX)
|
0~6000 adjustable
|
|
Illumination Difference((LX)
|
≤±500
|
|
Timing Range
|
1~99 hours/period
|
|
Cooling System
|
Imported compressor
|
|
Controller
|
Programmable (LCD display)
|
|
Sensor
|
PT100
Capacitance sensor |
|
Ambient Temperature
|
RT+5~30℃
|
|
Power Supply
|
AC 220V± 10% ,50HZ
|
|
Power Rating(W)
|
1650
|
|
Chamber Volume(L)
|
175
|
|
Chamber Size(W × D × H)mm
|
450×420×930(Support Customized)
|
|
Shelf
|
3
|
|
Printer
|
Yes
|
|
Safety Device
|
Compressor overheating and over pressure protection，Fan overheating protection, Over temperature
protection, Overload protection,water shortage protection |
