Altitude Test Chamber

  Altitude test chamber, namely High-low temperature and low pressure test chamber or Low pressure test chamber.  Can be used in electrical products, materials, spare parts, equipment, etc, for single featured test–high temperature, low temperature and altitude(under 30,000 or 45,000 meters) test and comprehensive test— heat-and-cool circulation test, temperature-and-altitu ...
SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

  • PRODUCT DETAIL



Altitude test chamber, namely High-low temperature and low pressure test chamber or Low pressure test chamber.  Can be used in electrical products, materials, spare parts, equipment, etc, for single featured test–high temperature, low temperature and altitude(under 30,000 or 45,000 meters) test and comprehensive test— heat-and-cool circulation test, temperature-and-altitude test.

Applications:

  • Aerospace
  • Metal Parts
  • Electronics
  • Car Spare Parts
  • Communication Equipment
  • Battery

Specification:

Model JY-ETC-408M JY-ETC-800M JY-ETC-1000M
Inner size (W*H*D) 80*85*60 100*100*80 100*100*100
Pressure range 101kPa ~ 0.5kPa
Temperature / Humidity range -70℃ ~ 150℃ / 20% ~ 98%R.H. Optional
Boost and Step-down time Boost : ≤10.0kPa

Step-down time : Normal pressure ~ 10kPa ≤30min

Features:

1.Temperature: -70 ~170ºC
2.Altitude: ground to 100,000 feet
3.External pressure type box body structure and stainless steel tank design, rational air circulation system and scientific layout of heating, refrigerating system.
4.Adopts international brand of imported parts for cooling system to improve operation reliability
5.High precision and stable performance with touch screen controller, friendly Man-Machine interface.
6.Multiple layers of safe device , easy for maintenance.
7.Viewing window and cable ports are available.
8.Vacuum pump sized for climb/dive rate required by application
