NEK 502 Norwegian Standard Plugs and Socket-Outlets Gauges and IEC 60884-1 gauges

NEK 502 Norwegian Standard Plugs and Socket-Outlets Gauges

NEK 502 Norwegian Standard Plugs and Socket-Outlets Gauges and IEC 60884-1 gauges

No. Gauge Type Gauge Name Qty(pcs)
1 NEK502:2016
Figure 1
Gauges C1 for size of entry holes for plug pins(6.0/5.8) 2
2 NEK502:2016
Figure 2
Gauges C2 for checking of minimum withdrawal force
(C2A-3.8-200g/C2B-4.6-200g/C2C-300g)
3
3 NEK502:2016 Figure 3 Gauge C3 for acceptance of two-pole plugs 1
4 NEK502:2016
Figure 4
Gauge C4 for acceptance of two-pole plugs with side earthing contacts 1
5 NEK502:2016 Figure 6 Gauges C6 for fixing holes or slots(C6A/C6B) 2
6 NEK502:2016
Figure 7
C7A.B.C.D
Gauges C7 for distance to
point of first
contact(5.45/5.6/5.75/5.95)
4
7 NEK502:2016 Figure 8 Gauge C8 for wiring channel 1
8 NEK502:2016
Figure 9
Gauge C9 for pin diameter(2.5A/16A)
C9Ba,C9Bb
2
9 NEK502:2016 Figure 10 Gauges C10 for pin spacing 2
10 NEK502:2016
Figure 11
Gauges C11 for maximum opening of contact tubes 1
11 NEK502:2016 Figure 12 Gauge C12 for interchangeability 1
12 NEK502:2016
Figure 16
Gauge for non-acceptance of two-pole plugs without earthing contact 1
13 NEK502:2016
Figure 18
Gauge for checking impossibility of single-pole
insertion of plugs
1
14 NEK502:2016
Figure 19
Gauges for checking impossibility of single-pole insertion of plugs into socket-outlets (2.5A-Gauge A,16A-Gauge-B) 2
15 NEK502:2016
Figure 19a
Gauges for checking deformation of side
earthing contacts
1
16 NEK502:2016
Figure 21
Devices for checking the resistance to lateral strain 1
17 NEK502:2016
Figure 23
Device for measuring the contact pressure of
earthing contacts
1
18 NEK502:2016
Figure 25
Device for checking earthing contacts on two-pole
plugs with side earthing contacts
1
19 NEK502:2016
Figure 26
Gauge for checking the maximum withdrawal force 1
20 NEK502:2016
Figure 27
Gauge (test plug) used for checking:
Temperature rise,Breaking capacity, Normal operation and Maximum withdrawal forces.
2
NEK 502 Norwegian Standard Plugs and Socket-Outlets Gauges
NEK 502 Norwegian Standard Plugs and Socket-Outlets Gauges
_cuva
_cuva
_cuva
