DIN VDE 0620-1 Lehre 6 7 8 9 Plug And Socket Outlets Gauges

DIN-VDE-0620-1 Lehre 6 Plug Gauges for Pin Diameter Testing Lehre 6 – Lehre für den Stiftdurchmesser Germany plug and socket gauge is strictly designed and manufactured according to the relevant standard requirements of VDE0620-1:2010. This plug and socket test gauge is mainly used to test and inspect whether the structure and size of plugs and sockets conform to VDE0620-1:2010 standards ...
SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

  • PRODUCT DETAIL

DIN-VDE-0620-1 Lehre 6 Plug Gauges for Pin Diameter Testing

Lehre 6 – Lehre für den Stiftdurchmesser

Germany plug and socket gauge is strictly designed and manufactured according to the relevant standard requirements of VDE0620-1:2010.

This plug and socket test gauge is mainly used to test and inspect whether the structure and size of plugs and sockets conform to VDE0620-1:2010 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets and other similar areas.

DIN VDE 0620-1-2010 Lehre 7 Gauges for Test Pin Spacing for Plugs 2P + PE AC 16 A and 2P AC 16 A

Lehre 7 – Lehre für die Prüfung des Stiftabstandes bei Steckern 2P + AC 16 A und 2P AC 16 A

Germany plug and socket gauge is strictly designed and manufactured according to the relevant standard requirements of VDE0620-1:2010.

This plug and socket test gauge is mainly used to test and inspect whether the structure and size of plugs and sockets conform to VDE0620-1:2010 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets and other similar areas.

For more VDE 0620 Plug and socket outlets gauges, please feel free to contact us.

VDE Gauge list:
Figure numberProject nameNumber
DIN-VDE0620-1-Lehre6Pin diameter1 sets of /4 parts
DIN-VDE0620-1-Lehre7Pin distance1 /2 combination
DIN-VDE0620-1-Lehre8The maximum opening width of the contact jack1
DIN-VDE0620-1-Lehre9Interchangeability test plug gauge1
