IEC 62196-1:2025 Figure 10 – Gauge “B” for checking shutters 1N
Specifications:
• Material: Rigid steel wire
• Key dimensions (mm): ø50, ø30, 6, 85, ø1+0015
• Radius (r): 0.05 mm
• Calibration force: 1 N applied along the axis of the rigid steel wire
• Calibration requirement: When 1 N force is applied, the plane A – A’ is brought to practically the same level as the plane B – B’ due to the internal spring characteristic
1 rigid steel wire To calibrate the gauge,a push forceriof 1N is applied on the steel rigid wire in therdirection of its axis: the characteristics of the gauge internal spring shall be such that the surface A-A’ is brought practically to the same level as the surface B-B’ when this force is applied. Figure 10 – Gauge “B” for checking shutters
