IEC60335-2-24 Clause 21.102 75mm Test Probe

Product information: This test probe conforms to IEC60335-2-24 Clause 21.102,IEC60335-2-30 Clause 11.8. It is used for protection test on the lamps of household appliances.   Test method: Using a sphere probe whose diameter is 75±0.5㎜ to touch the lamp which is equipped with a lampshade with inconspicuous force. The sphere probe should not be able to touch the lamp.   Parameter: Probe diameter:75 ...
SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

  • PRODUCT DETAIL

Product information:

This test probe conforms to IEC60335-2-24 Clause 21.102,IEC60335-2-30 Clause 11.8.

It is used for protection test on the lamps of household appliances.



Test method:

Using a sphere probe whose diameter is 75±0.5㎜ to touch the lamp which is equipped with a lampshade with inconspicuous force. The sphere probe should not be able to touch the lamp.



Parameter

Probe diameter:75mm(The head is semicircle)

Probe length:100mm

Baffle diameter:100mm

Baffle thickness:10mm
