IEC61032 Figure 8 Test Probe 12

This pin is intended to be used on appliances for verifying the inaccessibility of hazardous live parts or hazardous mechanical parts which are liable to be touched accidentally by a tool, for example a screwdriver or similar pointed object in normal use. It meets IEC61032 figure 8 test probe 12. Handle is made of nylon while the tip is made of hardened steel. Customizable: It can be used for encl ...
SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

  • PRODUCT DETAIL

This pin is intended to be used on appliances for verifying the inaccessibility of hazardous live parts or hazardous mechanical parts which are liable to be touched accidentally by a tool, for example a screwdriver or similar pointed object in normal use. It meets IEC61032 figure 8 test probe 12. Handle is made of nylon while the tip is made of hardened steel.

Customizable: It can be used for enclosure protection test when open threaded hole of M6 at the end of the handle (connected with pull and push dynamometer).



Main specification and corresponding technical parameters:

Parameters /Model Long test pin probe JY-F812
1 Ф4±0.05
2 50±0.15
3 Ф25±0.2
4 4
5 Ф10
6 20

Access probes to hazardous live parts or hazardous mechanical parts

IEC61032 figure 8 test probe 12.

IEC61032 figure 8 test probe 12.

IEC61032 figure 8 test probe 12.

IEC61032 figure 8 test probe 12.

IEC61032 figure 8 test probe 12.

IEC61032 figure 8 test probe 12

Test probe 12 figure8

Test probe 12 figure8
